Kia Sportage V – 1.6 T-GDI MHEV AWD petrol hybrid

NQ5 · 118 kW / 160 hp

2024 - now · Petrol hybrid · 1,598 cc

Car Details →

11 parts matched to this engine · 5 departments

Not your engine? Choose another

Save this car and every part on the site shows whether it fits.

Parts for this car

A few parts matched to this engine

All Parts →

Car Details

Details may vary by version.

Engine

Fuel
Petrol hybrid
Made
From 2024
Engine code
G4FU
Power type
Mild hybrid (small electric helper)
Engine size
1,598 cc (1.6 litres)
Engine power
160 hp (118 kW) at 5,500 rpm
Total power
160 hp (118 kW)
Torque (pulling power)
265 Nm at 1,500 to 3,500 rpm
Cylinders
4, in a row (inline)
Turbo
Turbo
Fuel injection
Direct injection
Show 6 MoreShow Less
Valves
16 (4 per cylinder)
Valve system
CVVD
Bore x stroke
75.6 x 89 mm
Compression ratio
10.5:1
Engine position
Front, sideways (transverse)
Catalytic converter
Three-way catalytic converter

Fluids and capacities

Engine oil amount
4.8 litres
Engine oil grade
0W-20
Coolant
8.1 litres
Fuel tank
54 litres
Drive battery voltage
48 volts

Engine Oils for This Car →Coolants for This Car →

Gearbox and drive

Gearbox
7-speed automatic (twin-clutch)
Driven wheels
4x4 (all four wheels)

Wheels, brakes, suspension and steering

Tyre size
215/65 R17, 235/55 R18 or 235/50 R19
Wheel (rim) size
7J x 17, 7.5J x 18 or 7.5J x 19
Front brakes
Ventilated discs
Rear brakes
Discs
Steering
Rack and pinion, electric power steering
Show 2 MoreShow Less
Front suspension
Independent, McPherson type with coil spring and anti-roll bar
Rear suspension
Independent multi-link spring suspension with anti-roll bar

Tyres for This Car →

Size and weight

Body style
SUV
Seats
5
Doors
5
Length
4,515 mm
Width
1,865 mm
Height
1,650 mm
Weight (empty)
1,573 to 1,722 kg
Ground clearance
170 mm
Boot space
562 litres
Show 14 MoreShow Less
Boot space, rear seats folded
1,751 litres
Wheelbase
2,680 mm
Width with mirrors
2,080 mm
Front track
1,615 to 1,630 mm
Rear track
1,622 to 1,637 mm
Turning circle
10.92 metres
Maximum weight (loaded)
2,210 kg
Load it can carry
488 to 637 kg
Roof load
100 kg
Front overhang
905 mm
Rear overhang
930 mm
Approach angle
17 degrees
Departure angle
26.4 degrees
Ramp (breakover) angle
16.7 degrees

Speed and fuel use

Fuel use, mixed driving
7.2 l/100 km (about 13.9 km per litre)
Top speed
192 km/h
0 to 100 km/h
9.8 seconds
Show 2 MoreShow Less
CO2 emissions
162 g/km
Emission standard
Euro 6

Fuel use is from official tests; town driving usually uses more.

More

Towing, trailer with brakes
1,510 kg
Towing, trailer without brakes
750 kg
Weight on the tow bar
100 kg
Engine systems
Start-stop (engine switches off at lights), Particulate filter (DPF/GPF)
