Bosch
Guide Sleeve Kit, Brake Caliper, 1 987 470 708
TZS 94,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
Lexus CT – 200h petrol hybrid
ZWA10_ · ZWA10_ · 100 kW / 136 hp
2011 - now · Petrol hybrid · 1,798 cc
57 parts matched to this engine · 10 departments
Not your engine? Choose another
Save this car and every part on the site shows whether it fits.
Parts for this car
A few parts matched to this engine
All Parts →
Mann-FilterAir Filter, C 22 009
224 x 187 x 35 mm
TZS 144,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
RidexTiming Chain Tensioner, 571T0080
TZS 160,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
MahleCoolant Expansion Tank, CRT 330 000S
314 x 216 x 148 mm
TZS 221,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
RidexWiper Blade — 650mm, 298W0070, Front
TZS 37,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BremboPrime Brake Pad Set — 123mm, P 83 106
123 x 50 mm
TZS 120,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
Car Details
Details may vary by version.
Engine
- Fuel
- Petrol hybrid
- Made
- From 2011
- Engine code
- 2ZR-FXE
- Power type
- Full hybrid (self-charging)
- Engine size
- 1,798 cc (1.8 litres)
- Engine power
- 98 to 99 hp (72 to 73 kW) at 5,200 rpm
- Total power
- 134 to 136 hp (99 to 100 kW)
- Torque (pulling power)
- 142 Nm
- Cylinders
- 4, in a row (inline)
- Turbo
- No turbo (naturally aspirated)
- Fuel injection
- Multi-point injection
Show 6 MoreShow Less
- Valves
- 16 (4 per cylinder)
- Valve system
- DOHC
- Bore x stroke
- 80.5 x 88.3 to 88.4 mm
- Compression ratio
- 13:1
- Engine position
- Front, sideways (transverse)
- Electric motor power
- 82 hp (60 kW)
Fluids and capacities
- Engine oil amount
- 4.2 litres
- Engine oil grade
- 0W-20
- Coolant
- 6.5 litres
- Fuel tank
- 45 litres
Show 2 MoreShow Less
- Drive battery type
- Nickel-metal hydride (NiMH)
- Drive battery voltage
- 201.6 volts
Gearbox and drive
- Gearbox
- Automatic (hybrid e-CVT)
- Driven wheels
- Front-wheel drive
Wheels, brakes, suspension and steering
- Tyre size
- 195/65 R15, 215/45 R17 or 205/55 R16
- Wheel (rim) size
- 7J x 17, 5J x 15, 5.5J x 15 or 6J x 16
- Front brakes
- Ventilated discs
- Rear brakes
- Discs
- Steering
- Rack and pinion, electric power steering
Show 2 MoreShow Less
- Front suspension
- Independent, McPherson type
- Rear suspension
- Double wishbone
Size and weight
- Body style
- Hatchback
- Seats
- 5
- Doors
- 5
- Length
- 4,320 to 4,351 mm
- Width
- 1,765 mm
- Height
- 1,440 to 1,455 mm
- Weight (empty)
- 1,370 to 1,465 kg
- Ground clearance
- 130 to 145 mm
- Boot space
- 375 litres
Show 10 MoreShow Less
- Boot space, rear seats folded
- 985 litres
- Wheelbase
- 2,600 to 2,601 mm
- Front track
- 1,524 to 1,535 mm
- Rear track
- 1,519 to 1,530 mm
- Turning circle
- 10.4 metres
- Maximum weight (loaded)
- 1,790 to 1,845 kg
- Load it can carry
- 325 to 475 kg
- Roof load
- 75 kg
- Front overhang
- 920 mm
- Rear overhang
- 800 mm
Speed and fuel use
- Fuel use, mixed driving
- 3.6 to 4.4 l/100 km (about 22.7 to 27.8 km per litre)
- Fuel use in town
- 3.6 to 4.7 l/100 km (about 21.3 to 27.8 km per litre)
- Fuel use on the highway
- 3.5 to 4.1 l/100 km (about 24.4 to 28.6 km per litre)
- Top speed
- 180 km/h
- 0 to 100 km/h
- 10.3 seconds
Show 2 MoreShow Less
- CO2 emissions
- 82 to 101 g/km
- Emission standard
- Euro 5 or Euro 6
Fuel use is from official tests; town driving usually uses more.
More
- Air drag (Cd)
- 0.29
