Mercedes-Benz CLC – CLC 180 1.8 Kompressor petrol
CL203 · 203.746 · 105 kW / 143 hp
2008 - 2011 · Petrol
180 parts matched to this engine · 11 departments
Not your engine? Choose another
Save this car and every part on the site shows whether it fits.
Departments for this car
A few parts matched to this engine
All Departments →
TRWTrailing Arm / Suspension Arm Bush, JBU167
TZS 59,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
TotalEnergiesDA Central Hydraulic Oil — 1L, 213756
TZS 82,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BoschCamshaft Position Sensor, 0 232 103 114
TZS 148,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BoschClutch Master Cylinder, 0 986 486 064
TZS 214,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
Febi BilsteinExpansion Tank Cap, 30533
TZS 55,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
Car Details
Details may vary by version.
Engine
- Fuel
- Petrol
- Made
- 2008 - 2011
- Engine code
- M 271.946
- Engine size
- 1,796 cc (1.8 litres)
- Engine power
- 143 hp (105 kW) at 5,200 rpm
- Torque (pulling power)
- 220 Nm at 2,500 to 4,200 rpm
- Cylinders
- 4, in a row (inline)
- Turbo
- Supercharger
- Fuel injection
- Multi-point injection
Show 6 MoreShow Less
- Valves
- 16 (4 per cylinder)
- Valve system
- DOHC
- Bore x stroke
- 82 x 85 mm
- Compression ratio
- 9.3:1
- Engine position
- Front, lengthways (longitudinal)
- Catalytic converter
- Three-way catalytic converter
Fluids and capacities
- Engine oil amount
- 5.5 litres
- Engine oil grade
- 0W-30, 0W-40, 5W-30 or 5W-40
- Coolant
- 8 litres
- Fuel tank
- 62 litres
Gearbox and drive
- Gearbox
- 6-speed manual or 5-speed automatic
- Driven wheels
- Rear-wheel drive
Wheels, brakes, suspension and steering
- Tyre size
- 205/55 R16 or 225/45 R17
- Wheel (rim) size
- 7J x 16 or 7.5J x 17
- Front brakes
- Ventilated discs
- Rear brakes
- Discs
- Steering
- Rack and pinion, hydraulic power steering
Show 2 MoreShow Less
- Front suspension
- Independent, McPherson type with coil spring and anti-roll bar
- Rear suspension
- Independent multi-link spring suspension with anti-roll bar
Size and weight
- Body style
- Coupe
- Seats
- 4
- Doors
- 3
- Length
- 4,448 mm
- Width
- 1,728 mm
- Height
- 1,405 mm
- Weight (empty)
- 1,400 to 1,420 kg
- Boot space
- 310 litres
Show 11 MoreShow Less
- Boot space, rear seats folded
- 1,100 litres
- Wheelbase
- 2,715 mm
- Width with mirrors
- 2,078 mm
- Front track
- 1,505 mm
- Rear track
- 1,476 mm
- Turning circle
- 10.76 metres
- Maximum weight (loaded)
- 1,945 kg
- Load it can carry
- 525 to 545 kg
- Roof load
- 100 kg
- Front overhang
- 842 mm
- Rear overhang
- 891 mm
Speed and fuel use
- Fuel use, mixed driving
- 7.7 to 8.3 l/100 km (about 12 to 13 km per litre)
- Fuel use in town
- 11 to 11.7 l/100 km (about 8.5 to 9.1 km per litre)
- Fuel use on the highway
- 5.7 to 6.4 l/100 km (about 15.6 to 17.5 km per litre)
- Top speed
- 215 to 220 km/h
- 0 to 100 km/h
- 9.7 to 9.9 seconds
Show 2 MoreShow Less
- CO2 emissions
- 182 to 198 g/km
- Emission standard
- Euro 4
Fuel use is from official tests; town driving usually uses more.
More
- Air drag (Cd)
- 0.29
