Mercedes-Benz GLE – AMG GLE 63 S EQ Boost 4-Matic+ petrol hybrid

W167 · 167.189 · 450 kW / 612 hp

2018 - now · Petrol hybrid

Car Details →

43 parts matched to this engine · 9 departments

Not your engine? Choose another

Save this car and every part on the site shows whether it fits.

Parts for this car

A few parts matched to this engine

All Parts →

Car Details

Details may vary by version.

Engine

Fuel
Petrol hybrid
Made
From 2018
Engine code
M 177.980 or M 177 Evo
Power type
Mild hybrid (small electric helper)
Engine size
3,982 cc (4 litres)
Engine power
612 hp (450 kW)
Total power
612 hp (450 kW)
Torque (pulling power)
850 Nm at 2,500 to 4,500 rpm
Cylinders
8, in a V
Turbo
Twin turbo
Fuel injection
Direct injection
Show 7 MoreShow Less
Valves
32 (4 per cylinder)
Valve system
DOHC, CAMTRONIC
Bore x stroke
83 x 92 mm
Compression ratio
8.6:1
Engine position
Front, lengthways (longitudinal)
Electric motor power
22 to 23 hp (16 to 17 kW)
Catalytic converter
Three-way catalytic converter

Fluids and capacities

Engine oil amount
9.5 litres
Engine oil grade
0W-40 or 5W-40
Fuel tank
85 litres
Drive battery size
0.9 kWh
Show 2 MoreShow Less
Drive battery type
Lithium-ion
Drive battery voltage
48 volts

Engine Oils for This Car →

Gearbox and drive

Gearbox
9-speed automatic
Driven wheels
4x4 (all four wheels)

Wheels, brakes, suspension and steering

Tyre size
275/45 R21, 315/40 R21, 285/40 R22 or 325/35 R22
Wheel (rim) size
10J x 21, 11J x 21, 10J x 22 or 11.5J x 22
Front brakes
Ventilated discs
Rear brakes
Ventilated discs
Steering
Rack and pinion, electric power steering
Show 2 MoreShow Less
Front suspension
Double wishbone, Anti-roll bar, Air suspension
Rear suspension
Independent multi-link suspension, Air suspension, Anti-roll bar

Size and weight

Body style
SUV
Seats
5 or 7
Doors
5
Length
4,938 to 4,947 mm
Width
2,018 mm
Height
1,782 to 1,783 mm
Weight (empty)
2,345 to 2,485 kg
Ground clearance
205 mm
Boot space
630 litres
Show 12 MoreShow Less
Boot space, rear seats folded
1,380 to 2,055 litres
Wheelbase
2,935 to 2,995 mm
Width with mirrors
2,157 to 2,164 mm
Front track
1,693 mm
Rear track
1,720 mm
Turning circle
12.4 to 12.5 metres
Maximum weight (loaded)
3,120 to 3,140 kg
Load it can carry
655 to 775 kg
Roof load
100 kg
Approach angle
25 degrees
Departure angle
25 degrees
Ramp (breakover) angle
17 degrees

Speed and fuel use

Fuel use, mixed driving
11.5 to 13.6 l/100 km (about 7.4 to 8.7 km per litre)
Fuel use in town
15.3 l/100 km (about 6.5 km per litre)
Fuel use on the highway
9.3 l/100 km (about 10.8 km per litre)
Top speed
280 km/h
0 to 100 km/h
3.8 to 3.9 seconds
Show 2 MoreShow Less
CO2 emissions
262 to 308 g/km
Emission standard
Euro 6

Fuel use is from official tests; town driving usually uses more.

More

Towing, trailer with brakes
3,500 kg
Towing, trailer without brakes
750 kg
Weight on the tow bar
140 kg
Engine systems
Start-stop (engine switches off at lights), Particulate filter (DPF/GPF); on some versions: cylinder deactivation
