Mercedes-Benz Vaneo – 1.6 petrol
W414 · 414.700 · 60 kW / 82 hp
2002 - 2005 · Petrol
78 parts matched to this engine · 11 departments
Not your engine? Choose another
Save this car and every part on the site shows whether it fits.
Departments for this car
A few parts matched to this engine
All Departments →
Mann-FilterAir Filter Suitable, C 1381
TZS 37,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
TotalEnergiesDA Central Hydraulic Oil — 1L, 213756
TZS 82,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BoschClutch Master Cylinder, 0 986 486 108
TZS 243,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
RidexWiper Blade — 400mm, 298W0046, Front
TZS 19,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
Car Details
Engine
- Fuel
- Petrol
- Made
- 2002 - 2005
- Engine code
- M 166 E 16 LR/166.961
- Engine size
- 1,598 cc (1.6 litres)
- Engine power
- 82 hp (60 kW) at 5,000 rpm
- Torque (pulling power)
- 140 Nm at 2,500 rpm
- Cylinders
- 4, in a row (inline)
- Turbo
- No turbo (naturally aspirated)
- Fuel injection
- Multi-point injection
Show 5 MoreShow Less
- Valves
- 8 (2 per cylinder)
- Valve system
- OHC
- Bore x stroke
- 80 x 79.5 mm
- Compression ratio
- 11.1:1
- Engine position
- Front, sideways (transverse)
Fluids and capacities
- Engine oil amount
- 5 litres
- Engine oil grade
- 5W-40
- Coolant
- 6 litres
- Fuel tank
- 54 litres
Gearbox and drive
- Gearbox
- 5-speed manual
- Driven wheels
- Front-wheel drive
Wheels, brakes, suspension and steering
- Tyre size
- 185/60 R15
- Front brakes
- Ventilated discs
- Rear brakes
- Discs
- Steering
- Rack and pinion, hydraulic power steering
Show 2 MoreShow Less
- Front suspension
- Suspension strut
- Rear suspension
- Coil spring
Size and weight
- Body style
- Minivan
- Seats
- 5
- Doors
- 5
- Length
- 4,190 mm
- Width
- 1,740 mm
- Height
- 1,830 mm
- Weight (empty)
- 1,290 kg
- Boot space
- 150 litres
Show 6 MoreShow Less
- Boot space, rear seats folded
- 3,000 litres
- Wheelbase
- 2,900 mm
- Front track
- 1,525 mm
- Rear track
- 1,475 mm
- Maximum weight (loaded)
- 1,910 kg
- Load it can carry
- 620 kg
Speed and fuel use
- Fuel use, mixed driving
- 7.8 l/100 km (about 12.8 km per litre)
- Fuel use in town
- 10.4 l/100 km (about 9.6 km per litre)
- Fuel use on the highway
- 6.4 l/100 km (about 15.6 km per litre)
- Top speed
- 157 km/h
- 0 to 100 km/h
- 15.8 seconds
Fuel use is from official tests; town driving usually uses more.
