Mercedes-Benz Vaneo – 1.7 CDI diesel
W414 · 414.700 · 67 kW / 91 hp
2002 - 2005 · Diesel
87 parts matched to this engine · 11 departments
Not your engine? Choose another
Save this car and every part on the site shows whether it fits.
Departments for this car
A few parts matched to this engine
All Departments →
Mann-FilterAir Filter Suitable, C 11 120
TZS 59,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
TotalEnergiesDA Central Hydraulic Oil — 1L, 213756
TZS 82,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BoschCrankshaft Sensor, 0 261 210 170
TZS 134,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BoschClutch Master Cylinder, 0 986 486 108
TZS 243,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
RidexWiper Blade — 400mm, 298W0046, Front
TZS 19,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
Car Details
Details may vary by version.
Engine
- Fuel
- Diesel
- Made
- 2002 - 2005
- Engine code
- OM 668DE 17 LA/668.914 or OM 668 DE 17 LA/668.914
- Engine size
- 1,689 cc (1.7 litres)
- Engine power
- 91 hp (67 kW) at 4,200 rpm
- Torque (pulling power)
- 180 Nm at 1,600 rpm
- Cylinders
- 4, in a row (inline)
- Turbo
- Turbo
- Fuel injection
- Common-rail diesel injection
Show 6 MoreShow Less
- Valves
- 16 (4 per cylinder)
- Valve system
- DOHC
- Bore x stroke
- 80 x 84 mm
- Compression ratio
- 19:1
- Engine position
- Front, sideways (transverse)
- Catalytic converter
- Diesel oxidation catalyst
Fluids and capacities
- Engine oil amount
- 5 litres
- Engine oil grade
- 5W-40
- Coolant
- 6 litres
- Fuel tank
- 54 litres
Gearbox and drive
- Gearbox
- 5-speed manual or 5-speed automatic
- Driven wheels
- Front-wheel drive
Wheels, brakes, suspension and steering
- Tyre size
- 185/60 R15
- Wheel (rim) size
- 15 inch
- Front brakes
- Ventilated discs
- Rear brakes
- Discs
- Steering
- Rack and pinion, hydraulic power steering
Show 2 MoreShow Less
- Front suspension
- Suspension strut
- Rear suspension
- Coil spring
Size and weight
- Body style
- Minivan
- Seats
- 5
- Doors
- 5
- Length
- 4,190 mm
- Width
- 1,740 mm
- Height
- 1,830 mm
- Weight (empty)
- 1,350 kg
- Boot space
- 150 litres
Show 6 MoreShow Less
- Boot space, rear seats folded
- 3,000 litres
- Wheelbase
- 2,900 mm
- Front track
- 1,525 mm
- Rear track
- 1,475 mm
- Maximum weight (loaded)
- 1,980 kg
- Load it can carry
- 630 kg
Speed and fuel use
- Fuel use, mixed driving
- 5.9 to 6.6 l/100 km (about 15.2 to 16.9 km per litre)
- Fuel use in town
- 7.4 to 8.4 l/100 km (about 11.9 to 13.5 km per litre)
- Fuel use on the highway
- 5.1 to 5.6 l/100 km (about 17.9 to 19.6 km per litre)
- Top speed
- 156 to 162 km/h
- 0 to 100 km/h
- 14 to 16 seconds
Fuel use is from official tests; town driving usually uses more.
