Mitsubishi OUTLANDER III – 2.4 Hybrid 4WD petrol

GG_W, GF_W, ZJ · 165 kW / 224 hp

2019 - now · Petrol hybrid · 2,360 cc

Car Details →

37 parts matched to this engine · 8 departments

Not your engine? Choose another

Save this car and every part on the site shows whether it fits.

Parts for this car

A few parts matched to this engine

All Parts →

Car Details

Engine

Fuel
Petrol hybrid
Made
From 2019
Engine code
4B12
Power type
Plug-in hybrid
Engine size
2,360 cc (2.4 litres)
Engine power
135 hp (99 kW) at 4,500 rpm
Total power
224 hp (165 kW)
Torque (pulling power)
211 Nm at 4,500 rpm
Cylinders
4, in a row (inline)
Turbo
No turbo (naturally aspirated)
Fuel injection
Multi-point injection
Show 6 MoreShow Less
Valves
16 (4 per cylinder)
Valve system
DOHC
Bore x stroke
88 x 97 mm
Compression ratio
12:1
Engine position
Front, sideways (transverse)
Catalytic converter
Three-way catalytic converter

Fluids and capacities

Engine oil amount
4.6 litres
Engine oil grade
0W-20
Coolant
6.5 litres
Fuel tank
45 litres
Drive battery size
13.8 kWh
Show 2 MoreShow Less
Drive battery type
Lithium-ion
Drive battery voltage
300 volts

Engine Oils for This Car →Coolants for This Car →

Gearbox and drive

Driven wheels
4x4 (all four wheels)

Wheels, brakes, suspension and steering

Tyre size
215/70 R16 or 225/55 R18
Wheel (rim) size
6.5J x 16 or 7J x 18
Front brakes
Ventilated discs
Rear brakes
Discs
Steering
Rack and pinion, electric power steering
Show 2 MoreShow Less
Front suspension
Independent, McPherson type with coil spring and anti-roll bar
Rear suspension
Independent multi-link spring suspension with anti-roll bar

Tyres for This Car →

Size and weight

Body style
SUV
Seats
5
Doors
5
Length
4,695 mm
Width
1,800 mm
Height
1,710 mm
Weight (empty)
1,880 kg
Ground clearance
190 mm
Boot space
463 litres
Show 14 MoreShow Less
Boot space, rear seats folded
1,602 litres
Wheelbase
2,670 mm
Width with mirrors
2,120 mm
Front track
1,540 mm
Rear track
1,540 mm
Turning circle
10.6 metres
Maximum weight (loaded)
2,390 kg
Load it can carry
510 kg
Roof load
80 kg
Front overhang
990 mm
Rear overhang
1,035 mm
Approach angle
21 degrees
Departure angle
22.5 degrees
Ramp (breakover) angle
19 degrees

Speed and fuel use

Fuel use, mixed driving
1.8 l/100 km (with a charged battery)
Top speed
170 km/h
0 to 100 km/h
10.5 seconds
Electric-only range
45 km
Show 2 MoreShow Less
CO2 emissions
40 g/km
Emission standard
Euro 6

Fuel use is from official tests; town driving usually uses more.

More

Towing, trailer with brakes
1,500 kg
Towing, trailer without brakes
750 kg
Weight on the tow bar
75 kg
Engine systems
Start-stop (engine switches off at lights)
