Volkswagen Caddy III Estate – 1.2 TSI petrol
2KB, 2KJ, 2CB, 2CJ · 63 kW / 86 hp
2004 - 2015 · Petrol
224 parts matched to this engine · 11 departments
Not your engine? Choose another
Save this car and every part on the site shows whether it fits.
Departments for this car
A few parts matched to this engine
All Departments →
TRWSteering Rack Gaiter, JBE323, Front
TZS 34,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BoschClutch Master Cylinder, 0 986 486 153
TZS 299,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
BoschDeflection / Guide Pulley, 1 987 600 011
TZS 80,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
MahleFan, Radiator, CFF 170 000S, Left
TZS 632,000Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
RidexWing Mirror Glass, 1914M0112, Right
TZS 49,500Order-in · 5 to 20 daysOrder-in 5 to 20 daysOrder-in
Car details
Details may vary by version.
Engine
- Fuel
- Petrol
- Made
- 2004 - 2015
- Engine code
- CBZA
- Engine size
- 1,197 cc (1.2 litres)
- Engine power
- 86 hp (63 kW) at 4,800 rpm
- Torque (pulling power)
- 160 Nm at 1,500 to 3,500 rpm
- Cylinders
- 4, in a row (inline)
- Turbo
- Turbo
- Fuel injection
- Direct injection
Show 4 moreShow less
- Valves
- 16 (4 per cylinder)
- Bore x stroke
- 71 x 75.6 mm
- Compression ratio
- 10:1
- Engine position
- Front, sideways (transverse)
Fluids and capacities
- Engine oil amount
- 3.6 litres
- Fuel tank
- 60 litres
Gearbox and drive
- Gearbox
- 5-speed manual
- Driven wheels
- Front-wheel drive
Wheels, brakes, suspension and steering
- Tyre size
- 195/65 R15, 205/55 R16 or 205/50 R17
- Wheel (rim) size
- 6J x 15, 6J x 16 or 6J x 17
- Front brakes
- Ventilated discs
- Rear brakes
- Discs
- Steering
- Rack and pinion, electric power steering
Show 2 moreShow less
- Front suspension
- Independent, McPherson type with coil spring and anti-roll bar
- Rear suspension
- Leaf spring
Size and weight
- Body style
- Minivan
- Seats
- 5 or 7
- Doors
- 5
- Length
- 4,406 mm
- Width
- 1,794 mm
- Height
- 1,823 mm
- Weight (empty)
- 1,388 kg
- Ground clearance
- 159 mm
- Boot space
- 918 litres
Show 8 moreShow less
- Boot space, rear seats folded
- 3,200 litres
- Wheelbase
- 2,681 mm
- Width with mirrors
- 2,062 mm
- Turning circle
- 11.1 metres
- Maximum weight (loaded)
- 2,180 kg
- Load it can carry
- 792 kg
- Front overhang
- 878 mm
- Rear overhang
- 847 mm
Speed and fuel use
- Fuel use, mixed driving
- 6.8 l/100 km (about 14.7 km per litre)
- Fuel use in town
- 8.1 l/100 km (about 12.3 km per litre)
- Fuel use on the highway
- 6 l/100 km (about 16.7 km per litre)
- Top speed
- 155 km/h
- 0 to 100 km/h
- 14.7 seconds
Show 2 moreShow less
- CO2 emissions
- 158 g/km
- Emission standard
- Euro 5
Fuel use is from official tests; town driving usually uses more.
